Aluminum-Rim Straightening Machine
Description
● Full automatic rim straightening machine alloy wheel processing machine with full teeth dual cylinder jack RSM595-F Features full teeth ,dual orthree cylinder jacks.
● This unique machine is used to correct and straighten all kinds Of defected steel and alloy rims ranging from 10"to 22'.
●As you have seen above formula you can have 5 tons of total pressure while working on our machines.
| Parameter | |
| Project | Specification |
| Wheel repair size | 026*22inch |
| Mechanic | 0.75 Kw |
| Hydraulic | 1.5 Kw |
| Max pressure | 15 mpa |
| Weight | 360 Kg/400kg |
| Voltage | 220V-single phase/380V-3 phase |
| Machine size(L*W*H)(L*W*H) | 1200*720*1980 mm |
Character
● Full automatic rim straightening machine alloy wheel processing machine with full teeth dual cylinder jack. ●RSM595-F Features full teeth ,dual orthree cylinder jacks.
● This unique machine is used to correct and straighten all kindsOf defected steel and alloy rims ranging from 10"to 22'.
●As you have seen above formula you can have 5 tons of total pressure while working on our machines.
| Parameter | |
| Project | Specification |
| Wheel repair size | 026*22inch |
| Mechanic | 0.75 Kw |
| Hydraulic | 1.5 Kw |
| Max pressure | 15 mpa |
| Weight | 290 Kg/310kg |
| Voltage | 220V-single phase/380V-3 phase, |
| Machine size(L*W*H)(L*W*H) | 1180*760*1980 mm |
Rim Straightening Machine is consist of balance testing ,machine work,hydraulic pressure straightening. It won't damage aluminum alloy molecule structure or mechanical property ,to repair various type of Auto Aluminum Alloy Rims.This equipment has been exported to America ,Australia ,Hungary,Russia,Middle east and etc,has enjoyed high reputation of customers worldwide.It is widely used in domestic automobile maintenance filed at present.It has advantage of convenient use and easy operation.It is the most ideal machine to make the rim restore its ideal using performance after break or distortion.
| Max.Working size:26"This machine must be used only for rim repairing operation.
Pay attention to the warning signs on the machine.
Machine Size:1390x1400x900 Machine weight:330kg
Noisy:75 db
Power supply:380V/220V/110V Motor power:0.75kw
Hydraulic motor power:1.1 kw |
Max.Workingsize:30"
Hydraulic motor power:1.5kw
Working pressure:15Mpa
Machine weight:220kg
Machine size:1000x600x1400mm |
Hydraulic Control Valve
Control Panel
anical Lathe
Hydrauic Control Valve
