Tyre Changer
Feature
●LT-770 is super-fast and super powerful.
● Some of the key features are fast one-position operation that takes half the steps.Tool returns to the same position on the wheel after each cycle,tall positioning pin eliminates adapters for front wheel drive, high offset wheels,and two-position detent mechanism limits travel of lower bead loosening shoe on narrow rims.
● Optional colors
| Parameter | |
| Rim Diameter | 12“-20” |
| Max wheel diameter | 737MM |
| Max.Wheel Width | 305MM |
| Diameter of cylinder | 178mm |
| Piston journey | 152mm |
| Cylinder volume | 21 liter |
| Cycle time | 9s |
| Noise level | <70dB |
| Net Weight | 216KG |
| Gross Weight | 267KG |
| Packing Dimension | 2030*1580*1000 |
Description
● With self-entering function
● Clamping system with stepping function
● Tilting back tower and pneumatic locking system
● Angle of mount/demount tool can be adjusted and calibrated
● The high quality polymer mounts/demounts tool prevents the rim from the damage.
● Plastic protector special for mounts/demountstool optional
● Wheel lift
●Adapter for motorcycle
● Bead seating inflation jets are integrated in the clamping jaws insuring quick and safe inflation
● Wear-resistant washer ●Portable air filling tank ●Optional colors
| Parameter | |
| Outside Clamping Range | 355-711mm |
| Inside Clamping Range | 305-660 |
| Max.Wheel Diameter | 1100mm |
| Wheel Width | 381mm |
| Air Pressure | 6-10 bar |
| Motor Power | 0.75/1.1kW |
| Noise Level | <70dB |
| NetWeight | 250kg |
Description
● With self-centering function.
●Clamping system with stepping function.
● Tilting column and pneumatic locking system
●Angle of mount/demount tool can be adjusted
and calibrated.
● The high quality polymer mounts/demounts tool prevents the rim from damage.
●Plastic protector special for mounts/demounts
tool.
●Assist arm AL-320C(Optional).
●Wheel lift(Optional).
●Portabe inflation tank.
● Bead seating inflation jets are integrated in the clamping
jaws insuring quick and safe inflation(Optional).
●Wear-resistant washer(Optional).
●Clamps for motorcycle(Optional).
| Parameter | |
| Outside Clamping Range | 355-711mm |
| Inside Clamping Range | 305-660 |
| Max.Wheel Diameter | 1100mm |
| Wheel Width | 381mm |
| Air Pressure | 6-10 bar |
| Motor Power | 0.75/1.1kW |
| Noise Level | <70dB |
| Net Weight | 250kg |
| Dimension of machine | 980*760*950m |
Description
●Round vertial column serves as quick inflation.
●With self-centering function.
● Clamping system with stepping function.
● Angle of mount/demount tool can be adjusted and calibrated.
● The high quality polymer mounts/demounts tool prevents the rim from damage.
●Mount/demount tool with plastic protector
● Wheel lift(Optional).
● Clamps for motorcycle(Optional).
● Bead seating inflation jets are integrated in the clamping jaws insuring quick and safe inflation(Optional).
| Parameter | |
| Outside Clamping Range | 279-610mm |
| Inside Clamping Range | 300-660 |
| Max.Wheel Diameter | 1100mm |
| Wheel Width | 381mm |
| Air Pressure | 6-10 bar |
| Motor Power | 0.75/1.1kW |
| Noise Level | <70dB |
| Net Weight | 263kg |
| Dimension of machine | 980*760*950m |
Description
●Round vertial column serves as quick inflation.
● With self-centering function.
●Clamping system with stepping function.
●Angle of mount/demount tool can be adjusted and calibrated.
● The high quality polymer mounts/ demounts tool prevents the rim from damage.
● Mount/demount tool with plastic protector.
●Wheel lift(Optional).
● May dispose the fluctuation cylinder
simple manipulator system(Optional). ●Clamps for motorcycle(Optional).
● Bead seating inflation jets are integrated in the clamping jaws insuring quick and safe
inflation(Optional).
| Parameter | |
| Outside Clamping Range | 305-660mm |
| Inside Clamping Range | 355-711 |
| Max.Wheel Diameter | 1100mm |
| Wheel Width | 381mm |
| Air Pressure | 6-10 bar |
| Motor Power | 0.75/1.1kW |
| Noise Level | <70dB |
| Net Weight | 250kg |
| Dimension of machine | 980*760*950mm |
