Wheel Balancer
Description
● With tire models conversion function,suitable for all kinds of small,medium and large tires.
● With function for multi dynamic and static balancing
● Multi-positioning way
●Self-calibration ensure a long service life
● Ounces/gram mm/inch conversion
●Unbalance value displayed accurately and the position to add the standard weights is indicted definitely
● With security interlock protection full-automatic pneumatic lift is used to the big size wheels
●Automatic pneumatic brake
● Manual locks positioning to make operation more conveniently;
●Optional four-hole/five-hole adapter.
| Parameter | |
| Rim Diameter | 10"-30" |
| Max.Wheel Diameter | 1200mm |
| Rim Width | 1.5"-11" |
| Max.Wheel Weight | 160kg |
| Rotation Speed | 100/200rpm |
| Air Pressure | 5-8 bar |
| Motor Power | 550W |
| Net Weight | 283kg |
| Dimension | 1300*990*1130mm |
Feature
● OPT balance function
●Multi-balancing choices for different wheel structures ●Multi-positioning ways
● Self-calibration program
●Ounce/gram mm/inch conversion
●Unbalance value displayed accurately and the position to add the standard weights is indicted definitely
● Hood-actuated auto-start
| Parameter | |
| Rim Diameter | 710mm |
| Max.Wheel Diameter | 1000mm |
| Rim Width | 254mm |
| Max.Wheel Weight | 65kg |
| Rotation Speed | 100/200rpm |
| Air Pressure | 5-8 bar |
| Motor Power | 250W |
| Net Weight | 120kg |
| Dimension | 1300*990*1130mm |
●In-column air tank
●Aluminum alloy large cylinder
●Explosion-proof oiler (Oil-Water separator)
● Built-in 40A switch
●5 aluminum alloy pedals
● Tire inflater with gauge
● Stainless steel adjustable mount/demount head
● They whole tire changer adopts metal joint connection with no failure rate ●CE certified
| Parameter | |
| Rim Diameter | 10"-24" |
| Max.Wheel Diameter | 1000mm |
| Rim Width | 1.5"-20" |
| Max.Wheel Weight | 65kg |
| Rotation Speed | 200rpm |
| Balance Precision | ±1g |
| Power Supply | 220V |
| Second Time M | ≤5g |
| Balance Period | 7s |
| Motor Power | 250W |
| NetWeight | 120kg |
● OPT balance function
●Multi-balancing choices for different wheel structures
●Multi-positioning ways
●Self-calibration program
●Ounce/gram mm/inch conversion
● Unbalance value displayed accurately and the position to add the standard weights is indicted definitely
● Hood-actuated auto-start
| Parameter | |
| Rim Diameter | 710mm |
| Max.Wheel Diameter | 1000mm |
| Rim Width | 254mm |
| Max.Wheel Weight | 65kg |
| Rotation Speed | 100/200rpm |
| Air Pressure | 5-8 bar |
| Motor Power | 250W |
| Net Weight | 120kg |
| Dimension | 1300*990*1130mm |
